Why does the PIV in centre tap rectifier is twice of the V source?

[null void]

In the full wave centre tap rectifier, piv of diode require is twice of the input current of the transformer. I can't understand why is it twice when the source is only 1V-peak.



[NascentOxygen]

In the full wave centre tap rectifier, piv of diode require is twice of the input current of the transformer. I can't understand why is it twice when the source is only 1V-peak.

Hi null void.

Have you drawn the schematic? If so, mark voltages on the secondary terminals, showing CT as ground, upper end +1V, and the lower end as -1V.

Then proceed to examine the diode inverse voltages from there.



[null void]

https://www.filesanywhere.com/fs/v.aspx?v=8b6a648c596070b5a3ac
That link contain a centre tap schematic circuit, not sure if there is anything i missed out.


Thanks NascentOxygen, but I don't really get it, what is CT?



[null void]

This is my just my assumption:

I consider the voltage drop at the resistance is same as the voltage drop at the reversed biased diode...am i right?



[Windadct]

Hello NV - When the DIode is fully reverse biased - what are the V on ether side of the diode?



[NascentOxygen]

This is my just my assumption:

I consider the voltage drop at the resistance is same as the voltage drop at the reversed biased diode...am i right?

CT is the centre tap, and that is grounded here. When one winding on the transformer has a voltage V volts, the other winding has a terminal voltage of -V volts. The conducting diode has no voltage loss across it. Mark these on your diagram, and you'll see what the voltage is on the reverse biased rectifier.

The load voltage is determined by the conducting diode.



[null void]

Opps accidentally replace the image of previous post. So i have to consider the forward biased diode as a jumper, and point a has voltage of V, and point B has voltage of 0V ?



[NascentOxygen]

Between point B and ground is a winding of the transformer! At the instant that A has a voltage of V volts (wrt ground), the voltage at point B has a voltage of -V volts (wrt ground) courtesy of its half of the transformer winding.



[null void]

Is that correct to view the circuit independently like in the diagram? How does the ground wire which direct connect to the transformer affect the circuit?



[sophiecentaur]

How are you defining the volts from the transformer? Is the "V" you have put on the diagram the volts referenced to Earth (i.e. is the transformer a V-0-V secondary)? It isn't clear from your sketch and it's vital for a proper answer.
But you have, basically a loop of wire from one end of the transformer to the other (you can ignore the resistor as it just appears in parallel with one of the windings) with a gap in it (the reverse biased diode). The voltage across that gap will be the same as the volts across the ends of transformer winding (=2V for a V-0-V transformer). Simples.



[null void]

sorry my V is the peak voltage of the transformer



[sophiecentaur]

sorry my V is the peak voltage of the transformer

Which "Peak Voltage"? There are three connections on it. (See my edit on my previous post)



[null void]

in a case of a series circuit with a transformer and a diode only, the voltage across the diode when it is reversebiased is also 2V_peak of the ac supplier source? or the transformer needto be grounded at the middle to create such condition?



[sophiecentaur]

If the total PD across the transformer are +V - (-V) =2V then it would have to be 2v.
This is why I was being picky about your use of the 'unqualified' value V. Do you take my point?
There is also the issue of Peak and RMS - which is why I slipped in the root 2 factor in my earlier post.
Grounding the centre tap is of no consequence, aamof, all that counts is the (vector) subtraction of the voltages at each end.
Note. If you only use one diode, there is a short circuit on the reverse cycle and what you say has no meaning. It's a totally different circuit that's required. You'd need to draw it out and it would be clearer.



[null void]

I am not sure if i am really get your point right now, the -V is the only thing bugging right now.



[NascentOxygen]

There are 2 identical secondary windings, and at any moment in time they produce identical voltages. So if you say there are V volts across one, then there must also be V volts across the other (regardless of whether there is current being drawn or not).

So for the situation depicted, with V volts across the lower winding, this places B at -V volts with respect to the other end of that winding (which being connected to earth, we call 0 volts).



[vk6kro]

As you can see, the center tap of the transformer is always at zero volts because it is grounded.

So the opposite ends of the transformer winding swing positive and negative relative to this ground connection and produce a peak voltage of 1.414 (√2) times the RMS voltage.

If you take the moment when the top winding produces a maximum positive voltage and the bottom winding produces a maximum negative voltage, there is a combined maximum reverse voltage across the bottom diode.
This is when it is most likely to fail and it has to be rated for at least this reverse voltage.



[null void]

There are 2 identical secondary windings, and at any moment in time they produce identical voltages.

this sound like what my lecturer said, he split the ac source into 2:

And if i am not wrong, each of the splited source can produce 0.5 of the V_peak. And is it because the circuit is somehow not completed, the voltage differnce across the the gap is same as the v_peak, like in this diagram:



[NascentOxygen]

EDIT: oops, I see you have it right after all.

Because the - of the upper source is earthed, then the upper winding delivers +V volts. Because the + of the lower is earthed (it shares the same centre tap), then the lower winding terminal delivers -V volts.



[NascentOxygen]

You have to get it clear in your mind and be consistent, either view it as one long winding producing 2V volts with a centre tap, or view it as two windings, each producing V volts.

If it's a 36V winding centre-tapped, then each half winding delivers 18V, and the output is 18V full wave rectified. This is the same as viewing it as a pair of 18V windings, with one end of each joined together and earthed (and phasing correct). Your second sketch with one winding showing no voltage is quite wrong.



[null void]

I didn't notice this at the beginning of the post, but after reading the posts you guys have posted, i slowly catch the idea. Thanks everyone for spending times on my problems :D



[null void]

I didn't notice this at the beginning of the post, but after reading the posts you guys have posted, i slowly catch the idea. Thanks everyone for spending times on my problems :D



[sophiecentaur]

There are 2 identical secondary windings, and at any moment in time they produce identical voltages. So if you say there are V volts across one, then there must also be V volts across the other (regardless of whether there is current being drawn or not).

So for the situation depicted, with V volts across the lower winding, this places B at -V volts with respect to the other end of that winding (which being connected to earth, we call 0 volts).

I'm sure you cannot mean that. The two windings of a centre tapped transformer are in antiphase - the terminal voltages are always of opposite polarity. (Otherwise there would be no point in having twice as many turns on the former). If one terminal is at +Peak volts, the other terminal is at -Peak volts.



[NascentOxygen]

I did mean that, because I was picturing a meter across each to measure the amplitude. I didn't want to complicate with phasing there, but mentioned it in parentheses later just in case OP was wondering.



[sophiecentaur]

I did mean that, because I was picturing a meter across each to measure the amplitude. I didn't want to complicate with phasing there, but mentioned it in parentheses later just in case OP was wondering.

But surely it's the phasing that makes the whole thing work. It is very misleading to imply that V is the same as -V, which is what you were implying. If you don't make it clear which end of the 'meter' is connected to what, it would naturally be assumed that the voltages would be referred to Ground. The two terminals have opposite signs of PD (relative to Ground). This is an idea that I have found missing throughout this thread and I think it's the reason that the OP has taken so long to understand things. It seems that he is now starting to get it - so it's been worth while I think.

There is, of course, the extra point that needs to be emphasised and that is the fact that the Earth and Resistive load connections are not, in fact, relevant to the the voltage drop situation 'around the loop' of transformer windings and diodes when calculating the PIV on each diode.



[null void]

So the tap play an important role? without it the piv will not be double?



[sophiecentaur]

So the tap play an important role? without it the piv will not be double?

Do you understand about transformer taps? A tap which is half way along the winding will have no effect on the total voltage across the winding (as long as there is not excessive current drawn via some path). As it happens, a centre-tapped transformer is normally specified as, say 100V-0-100V, meaning there is 200V across the whole winding and two 100V , antiphase outputs - relative to the centre tap (often, earthed). This is the configuration used in many power supplies with 'full wave' rectification (like yours).
I keep saying this but you don't seem to be taking it on board. It's the total voltage across the whole length of the winding that appears across the two series diodes. Chop off the Earth and resistor connections and that is obvious (?). I think the resistor and Earth connections must be confusing you but that diagram, earlier, with the two batteries, will also show my point. Disconnect the resistor and Earth and you have two batteries' worth of PIV on the open circuit diode. Re-connect them and you still have the same situation. On one end of the diode you have -V and the other end, connected to the resistor, has +V - making 2V across it. So it happens with or without the tap.



[null void]

Same as this? Voltage inversed = 24v ?



[sophiecentaur]

Same as this? Voltage inversed = 24v ?

Where does the 24V come from? You start with only one 12V battery so how can you get more? Have you ever come across Kirchoff's Laws?
Your transformer has TWO! voltage sources and not just one.



[null void]

You mean this? And the polarity of the the 2 source is same or opposite?



[NascentOxygen]

But surely it's the phasing that makes the whole thing work.

Indeed. But I sensed that OP may not have a good grasp of "phasing". That's why I referred to it as polarity, as you'll note in my 1st and 2nd posts in this thread.

There is, of course, the extra point that needs to be emphasised and that is

Many points may be emphasized to give a more thorough analysis, but I sensed that OP does not have too solid a grounding here. I kept to just the essentials to answer his* question, lest he get mired in indigestible detail.



[sophiecentaur]

You mean this? And the polarity of the the 2 source is same or opposite?

"Polarity" relative to what? There are three correct answers.
The same, relative to the bottom connection.
Opposite, relative to the mid point.
The same relative to the top.

If you live on the ground floor, everyone is 'above you'.
If you live half way up, some are above and some are below.
If you live on the top floor, everyone is below you.

You have to specify a reference and, in a circuit with an Earth connection, it is normal to use that as a reference. The centre tap is connected to Earth in your first diagram but that makes no difference to the voltage across the two ends. You could put a tap on the winding that is 1/4 way along it and connect that to Earth instead. The voltage across the winding would still be the same (2V). The lower terminal would be at (-)V/2 and the upper would be at +3V/2.

There is still something nagging at the back of your mind about this. I wish I could spot what it is. Then I could think of the magic words to sort it all out for you. Perhaps it's the word "Relative".



[NascentOxygen]

You mean this? And the polarity of the the 2 source is same or opposite?

The polarity is as you have them drawn. (I'm not going to say whether that should be termed "the same" or "opposite" because it depends on how you view them.)

But the polarity is as you have shown them.

So you can see that the PIV is equal to the sum of both windings?



[sophiecentaur]

Indeed. But I sensed that OP may not have a good grasp of "phasing". That's why I referred to it as polarity, as you'll note in my 1st and 2nd posts in this thread.


Many points may be emphasized to give a more thorough analysis, but I sensed that OP does not have too solid a grounding here. I kept to just the essentials to answer his* question, lest he get mired in indigestible detail.

Ah well, in that case he should not get involved with centre tapped transformers. Dual DC power supplies might be something to start off with.



[NascentOxygen]

Perhaps it's the word "Relative".

Indeed. It means something to me, but is unlikely to add clarity to OPs understanding.

(I actually used "relative polarity" in my last reply to poster, but then edited it out for being unlikely to mean much.)
