Control System Problem

  1. Sep 24, 2013 #1
    1. The problem statement, all variables and given/known data
    Since this is a third order system and there will be a zero in its transfer function i am confused that how the natural frequency and K will be linked ? Please do help i really get confused in these type of problems.


    2. Relevant equations



    3. The attempt at a solution
    1 st image in the attachments is the attempt, and second image is the question.

    1. The problem statement, all variables and given/known data



    2. Relevant equations



    3. The attempt at a solution


    Attached Files:

  2. jcsd
  3. Sep 24, 2013 #2

    rude man

    User Avatar
    Homework Helper
    Gold Member

    Assume Gc = (s+a)/(s+b) as you have done.

    Then the open-loop gain is GGc = (k/s2)[(s+a)/(s+b)] = n/d.

    Expand n + d into s3 + cs2 + ds + e

    and equate coefficients of like powers of s with

    (s2 + 2ζωns + ωn2)(s + αωn)
    which you also have to expand as above.

    By equating coefficients of like powers of s you get 3 equations with 3 unknowns (a, b and α).
    Solve for a and b.

    (k was not given numerically so you can assume any value which will agree with one of the four answer choices).

  4. Sep 24, 2013 #3
    Why do you have used (s + αωn) i mean how do you have "αωn" as a root of the characteristic equation ?

  5. Sep 24, 2013 #4

    rude man

    User Avatar
    Homework Helper
    Gold Member

    Good question.

    α is a new, dimensionless variable for a 3rd-order system. If you compare the inverse-Laplace transform for the 3rd-order chas. equation with the same xfr function for the 2nd order system, i.e. without the extra (s + αωn) term, you would get a similar time response to a delta function input except for a modified coefficient in front of the sine term, plus a second, non-sinusoidal, term. The second term decays as exp(-αωnt) whereas the sinusoidal part decays as exp(-ζωnt), same as for the 2nd-order system. The argument of the sine is the same for both 2nd and 3rd order systems
    = (ωn√(1 - ζ2)t + ψ).

    And the phase angle ψ(3rd order) = ψ(2nd order) - a term including α.

    So the bottom-line answer is that the two systems behave somewhat similarly if for the 3rd order system you retain the 2nd order expression multiplied by (s + αωn).

    The complete time response expression is a mess to write out & I'm not going to do it here, with or without the extra (s + αωn) in the chas. equation. I suggest you get hold of a very extensive Laplace transform table which includes the time responses to both cases.

  6. Sep 24, 2013 #5
    I am still not very much clear about the part the root of 3 rd order system including natural frequency.


    Attached Files:

  7. Sep 24, 2013 #6

    rude man

    User Avatar
    Homework Helper
    Gold Member

    Alpha is not arbitrarily chosen. You get 3 equations to solve for a, b and alpha.

    Can you get hold of a really good Laplace transform table?

    BTW your photos are 90 degrees twisted and very hard to read.

  8. Sep 24, 2013 #7
    sorry for the photos.

  9. Sep 24, 2013 #8
    I got 3 equations but what value of "k" should i take ?

  10. Sep 24, 2013 #9

    rude man

    User Avatar
    Homework Helper
    Gold Member

    Like I said, a constant that will make one of your answer choices correct. I think it was dumb of them not to give you a value for k. It was obviously an incompletely stated problem.

    I haven't done the work and don't want to, so here you're a bit on your own.

    EDIT: wait, did you solve for a(k) and b(k), and if so, what did you get?

    Last edited: Sep 24, 2013
  11. Sep 25, 2013 #10
    I have posted the Image.


    Attached Files:

  12. Sep 25, 2013 #11

    rude man

    User Avatar
    Homework Helper
    Gold Member

    OK, so then a = 5 - 125/k = (5k - 125)/k and
    b(k) = k/5

    So if you start with b(k), choice (a) would seem closest: b(k) = 9.9, k = 49.5, then a(k) ~ 2.5.

    As I said, I think it was dumb of them not to have given you k numerically since it certainly determines a and b.

  13. Oct 13, 2013 #12
    Thanks a lot and sorry for such a late reply, since i wasn't able to check my thread for a long time.But how did you come to conclusion of "k" being 49.5 ?

  14. Oct 13, 2013 #13

    rude man

    User Avatar
    Homework Helper
    Gold Member

    b(k) = k/5 so
    k = 5b(k)
    But b = 9.9
    Therefore k = 5*9.9 = 49.5

  15. Oct 15, 2013 #14
    can i ask another question over here only regarding electromagnetic fields or should i post another thread ?

  16. Oct 15, 2013 #15

    rude man

    User Avatar
    Homework Helper
    Gold Member

    I would start a new thread since control systems and e-m are very different disciplines.
