Sex education for SMA connectors

  • Thread starter Thread starter Paul Colby
  • Start date Start date
  • Tags Tags
    Education
Click For Summary

Discussion Overview

The discussion revolves around the naming conventions and designations of SMA connectors, particularly focusing on the distinctions between normal polarity (NP) and reverse polarity (RP) connectors. Participants explore the implications of these designations, their practical applications, and the potential confusion they create in the context of coaxial connections.

Discussion Character

  • Debate/contested
  • Technical explanation
  • Conceptual clarification

Main Points Raised

  • Some participants discuss the conventional definitions of "male" and "female" in the context of connectors, noting that typically a male connector has a protruding contact while a female connector has a receptacle.
  • Others highlight the confusion arising from RP SMA connectors, where the outer conductor may be male while the inner conductor is female, leading to questions about the naming conventions.
  • A participant mentions that the variations in connector types are partly due to the need for compatibility with different antennas, which may have specific connector requirements.
  • Some argue that the naming conventions are misleading, with one participant suggesting that RP connectors should be referred to as RP-MALE despite having female components.
  • There are discussions about the regulatory motivations behind the design of RP connectors, particularly in relation to FCC regulations that aim to prevent users from easily connecting non-approved antennas.
  • Several participants express frustration with the naming system, suggesting it complicates the purchasing process and leads to misunderstandings.
  • One participant humorously refers to the situation as a "sex change operation" for connectors, indicating the perceived absurdity of the naming conventions.
  • Links to external resources, including Wikipedia and connector basics, are shared to provide additional context and clarification on the topic.

Areas of Agreement / Disagreement

Participants express a mix of agreement and disagreement regarding the naming conventions and their implications. While some acknowledge the technical reasoning behind the designations, others find them confusing and poorly thought out. The discussion remains unresolved with multiple competing views on the appropriateness of the naming conventions.

Contextual Notes

Participants note that the naming conventions may not align with common understanding and that the designations can lead to practical issues when ordering connectors. There is also mention of the influence of regulatory bodies on connector design, which adds complexity to the discussion.

Paul Colby
Science Advisor
Insights Author
Messages
1,578
Reaction score
486
Okay, so I think I get the whole sex metaphor for coaxial connectors. I recently started buying SMA plumbing after I discovered RG-58 is essentially transparent in the FM band for my application. Now, typically a "male" designator refers to a connector having a little conducting protuberance while the corresponding "female" refers to a nice conducting receptacle for the aforementioned "male" bit. Okay, meanwhile in an alternate universe, "male" could refer to to the outer conductor equipped with exterior threads mating with the nice gold plated nut with interior threads. Okay, I buy 20 RP-FEMALE SMA bulkhead connectors only to discover that by the previous discussion the outer conductor is male and the inner conductor is also male. So, my question is two fold. A) In what convention system does this make sense. B) who on Earth would think making such a thing is a swell idea?

Engineering news on Phys.org
Paul Colby said:
Okay, so I think I get the whole sex metaphor for coaxial connectors. I recently started buying SMA plumbing after I discovered RG-58 is essentially transparent in the FM band for my application. Now, typically a "male" designator refers to a connector having a little conducting protuberance while the corresponding "female" refers to a nice conducting receptacle for the aforementioned "male" bit. Okay, meanwhile in an alternate universe, "male" could refer to to the outer conductor equipped with exterior threads mating with the nice gold plated nut with interior threads. Okay, I buy 20 RP-FEMALE SMA bulkhead connectors only to discover that by the previous discussion the outer conductor is male and the inner conductor is also male. So, my question is two fold. A) In what convention system does this make sense. B) who on Earth would think making such a thing is a swell idea?
LOL, funny thread title.

NP (normal polarity) has the male signal poke-out thing and inside threads on the outer nut/conductor/shield part.

RP (reverse polarity Female connectors have the female middle conductor, but have outside threads on the outer part (so that fits inside of the outer threads for the mating part.

One reason for the variations is that antennas have a couple variations of the connectors built-in, hence the need to have alternatives for mating with them.

EDIT / ADD -- https://en.wikipedia.org/wiki/SMA_connector

EDIT2 -- It looks like I may have mispoke about the center conductor determining the sex. From the wikipedia article:


Figure 2. Female RP-SMA connector: Female connector body (outside threads) with a male inner pin contact. A male RP-SMA connector is the opposite in both respects — male connector body (inside threads) with a female inner sleeve contact.

I always have to double-check the pictures when ordering RP SMA parts...


Attachments

  • 200px-Gniazdo_RPSMA.jpg
    11.7 KB · Views: 980
  • Like
Likes   Reactions: scottdave and Paul Colby
berkeman said:
One reason for the variations is that antennas have a couple variations of the connectors built-in, hence the need to have alternatives for mating with them.

Why introduce potential confusion? Of course the image you show wasn't available (the one missing view angle in fact) but until now the horror of such a possibly hadn't occurred to me.

Paul Colby said:
Why introduce potential confusion?
That's a valid question, with an interesting answer.

Many FCC-approved RF transceiver devices that have detachable antennas are approved only for the antenna the device was approved with during FCC testing. They don't want you to be able to easily connect a larger antenna with lots more gain via a standard SMA cable. So the output SMA connector on the device is RP, expecting an RP SMA antenna, not a standard polarity SMA coax cable. Of course, with SMA adapters, you can circumvent that issue, but that's one of the original reasons for the RP option. There could be others as well...

I would argue the proper name for the part I bought should be RP-MALE.

Paul Colby said:
RP-MALE.
This?

http://www.nghobbies.com/wp-content/uploads/2015/09/rp-sma-male.jpg


Attachments

  • rp-sma-male.jpg
    15 KB · Views: 1,124
The above would clearly be "RP-FEMALE".

Paul Colby said:
The above would clearly be "RP-FEMALE".
Apparently not. See the name in the link. And Wikipedia seems to say the "sex" goes with the outer conductors thread sense...

  • Like
Likes   Reactions: davenn
berkeman said:
Apparently not. See the name in the link. And Wikipedia seems to say the "sex" goes with the outer conductors thread sense...

Thread sense makes no sense, IMO. Unless of course if they are left-handed as well. They screwed up and they rely on people like me to buy their products by accident.

  • #10
Okay, one of my RP-FEMALE bulkhead connectors paid the ultimate price. I pulled the mislabeled male bit out. A standard NP-MALE connector screws on just fine so the handedness of the threads is right-handed.

  • #11
RP male has both female contact and female thread. It is still referred to as male because it is a normal SMA male that has had a sex change operation.
In other words "reversed male" = female

Last edited:
  • #12
Paul Colby said:
They screwed up...
:DD . :DD

  • Like
Likes   Reactions: Tom.G
  • #13
the_emi_guy said:
RP male has both female contact and female thread.It is still referred to as male because it is a normal SMA male that has had a sex change operation.
In other words "reversed male" = female

that really doesn't make sense and doesn't go with common info available

did you not read Berkeman's post #6 ?

  • #14
davenn said:
that really doesn't make sense and doesn't go with common info available

did you not read Berkeman's post #6 ?

What doesn't make sense?

That connectors that have all female parts would have the word "male" in their description, or my explanation of that odd situation?

Berkeman's post #6 is just a picture of an RP Male (with all of its female parts).

  • #15
It takes 2 bits of information to describe 4 possible configurations. Two of these configurations have been given stupid and misleading names. I will adjust to this situation though it may take some time to heal. Two of the configurations are in common usage and the other two are pointless from my perspective. While the "Let's make this inconvenient to plug a non-standard antenna in" explanation for the two pointless configurations may be industry standard, it is a lame excuse.

  • #16
Paul Colby said:
It takes 2 bits of information to describe 4 possible configurations. Two of these configurations have been given stupid and misleading names. I will adjust to this situation though it may take some time to heal. Two of the configurations are in common usage and the other two are pointless from my perspective. While the "Let's make this inconvenient to plug a non-standard antenna in" explanation for the two pointless configurations may be industry standard, it is a lame excuse.

Berkeman's "inconvenient to plug in" explanation is correct, and it was not initiated by engineers, but by lawyers at the FCC. Search for "unique connectors" in the attached fcc rules document.
As far as I know, no one uses these reversed connectors except to hack around FCC pre-approved antennas (or the folks making FCC approved equipment) so maybe it really doesn't matter what they are called.


Attachments

  • Like
Likes   Reactions: krater
  • #17
'Tis a fine madness...

http://www.amphenol-aerospace.com/connectorbasics

http://www.amphenol-aerospace.com/pdf/faq/knowconnectors.pdf


Attachments

  • upload_2017-12-24_1-7-25.png
    66.3 KB · Views: 1,249
  • #18
jim hardy said:
'Tis a fine madness...

http://www.amphenol-aerospace.com/connectorbasics

http://www.amphenol-aerospace.com/pdf/faq/knowconnectors.pdf
View attachment 217364
And circling back to the post title, check out the note at the bottom of page 29 of the knowconnectors.pdf link.

:DD

  • Like
Likes   Reactions: dlgoff and jim hardy
  • #19
the_emi_guy said:
And circling back to the post title, check out the note at the bottom of page 29 of the knowconnectors.pdf link.

But there's a wise guy in every design group.
Some wag just had to invent a "Hermaphroditic Connector" .

https://www.digikey.com/catalog/en/partgroup/hermaphroditic-connectors/24517#datasheets


Attachments

  • upload_2017-12-25_11-43-13.png
    38.3 KB · Views: 762
  • Like
Likes   Reactions: dlgoff
  • #20
the_emi_guy said:
And circling back to the post title, check out the note at the bottom of page 29 of the knowconnectors.pdf link.

:DD
:doh:

  • Like
Likes   Reactions: jim hardy
  • #21
jim hardy said:
Some wag just had to invent a "Hermaphroditic Connector" .
I've used some of that type, albeit decades ago. The sometimes un-appreciated utility is if you get the style that allows the contacts to be inserted in two positions (rotated 90°), you can key the connectors many different ways, specifically 2<No. of pins>. Useful in large systems. (But you better document it well!)

  • #22
jim hardy said:
Some wag just had to invent a "Hermaphroditic Connector" .
Lol, believe it or not, ambiguous gender, and genderless (hermaphroditic) connectors are the... "in or not in " thing now... . :DD

Last edited:
  • Like
Likes   Reactions: davenn
  • #23
OCR said:
Lol, believe it or not, ambiguous gender, and genderless (hermaphroditic) connectors are the... "in or not in " thing now... . :DD

over the last 15 years, one I have used dozens of are the genderless Anderson Power Pole connectors
@berkeman may be familiar with them... much loved in the amateur radio fraternity



Attachments

  • Sell_Anderson_Power_pole_Connector.jpg
    12.2 KB · Views: 591
  • Like
Likes   Reactions: berkeman
  • #24

Attachments

  • Gr-874-connector.jpg
    38.3 KB · Views: 537
  • Apc7_1.png
    16.6 KB · Views: 577
  • Like
Likes   Reactions: scottdave and dlgoff
