Back EMF: Phase-to-Phase Voltage Explained

  • Thread starter Thread starter PhysicsTest
  • Start date Start date
  • Tags Tags
    Motor
AI Thread Summary
Back EMF in motors is often discussed in terms of phase-to-phase voltage relationships, where the back EMF of each phase is defined relative to another phase. For instance, back EMF of phase A is measured with respect to phase B, while phase B's back EMF is measured against phase C, and so on. This concept is particularly relevant in field-oriented control systems. Understanding the reversible nature of transformers can provide insights into how most motors can also function as generators, generating back EMF or RPM-induced voltage. A deeper inquiry into these concepts can enhance comprehension of motor dynamics.
PhysicsTest
Messages
246
Reaction score
26
TL;DR Summary
Understanding of Back emf of PMSM motor
When the back emf of the motor is referred does it always refer to phase to phase voltage. For example
Back emf of A is A phase with respect to B phase? (A+, B-)
Back emf of B is B phase with respect to C phase? (B+, C-)
Back emf of C is C phase with respect to A phase? (C+, A-)
