MHB Explore Attraction Basins of Damped Double-Well Potential Model

[Dustinsfl]

I don't understand how to start.

Consider the damped double-well potential model
$$
\ddot{x} - x + x^3 + \gamma\dot{x} = 0,
$$
where $\gamma$ is the damping coefficient.
This model has two fixed points at $(x,\dot{x}) = (1,0)$ and $(-1,0)$. In the phase plane $(x,\dot{x})$, determine the attraction basins of these fixed points. You can decide which $\gamma$ value to use (try to choose one which gives the best picture/graph). Note: the attraction basin of a fixed point is the set of initial points which go to the fixed as $t\to\infty$.



[Dustinsfl]

I don't understand how to start.

Consider the damped double-well potential model
$$
\ddot{x} - x + x^3 + \gamma\dot{x} = 0,
$$
where $\gamma$ is the damping coefficient.
This model has two fixed points at $(x,\dot{x}) = (1,0)$ and $(-1,0)$. In the phase plane $(x,\dot{x})$, determine the attraction basins of these fixed points. You can decide which $\gamma$ value to use (try to choose one which gives the best picture/graph). Note: the attraction basin of a fixed point is the set of initial points which go to the fixed as $t\to\infty$.

Change the ODE to a system of ODEs, we have
\begin{alignat}{3}
x_1' & = & x_2\\
x_2' & = & x_1 - x_1^3 + \gamma x_2
\end{alignat}
When $\gamma = 1$, how do I find the attraction basin?



[Sudharaka]

Change the ODE to a system of ODEs, we have
\begin{alignat}{3}
x_1' & = & x_2\\
x_2' & = & x_1 - x_1^3 + \gamma x_2
\end{alignat}
When $\gamma = 1$, how do I find the attraction basin?

So with reference to http://www.mathhelpboards.com/f17/converting-ode-system-odes-2078/ thread your system of equations should be,

\[x_1'=x_2\]

\[x_2'=x_1-x_1^3-\gamma x_2\]

I don't know if this is helpful, but I have drawn the phase portrait of this system. Note that I have replaced, \(x_1\) by \(x\) and \(x_2\) by \(y\). If you have Maxima you can animate the graph so that you can find the phase portraits for different values of \(\gamma\). Here I have included graphs for several values of \(\gamma\).

\[x'=y\mbox{ and }y'=x-x^3-\gamma y\]

load("plotdf");

plotdf([y,x-x^3-a*y],[x,-5,5],[y,-5,5],[sliders,"a=-10:10"]);

\(\mathbf{\underline{\mbox{When }\gamma=0}}\)

\(\mathbf{\underline{\mbox{When }\gamma=2}}\)

\(\mathbf{\underline{\mbox{When }\gamma=-2}}\)



[Dustinsfl]

So with reference to http://www.mathhelpboards.com/f17/converting-ode-system-odes-2078/ thread your system of equations should be,

\[x_1'=x_2\]

\[x_2'=x_1-x_1^3-\gamma x_2\]

I don't know if this is helpful, but I have drawn the phase portrait of this system. Note that I have replaced, \(x_1\) by \(x\) and \(x_2\) by \(y\). If you have Maxima you can animate the graph so that you can find the phase portraits for different values of \(\gamma\). Here I have included graphs for several values of \(\gamma\).

\[x'=y\mbox{ and }y'=x-x^3-\gamma y\]

load("plotdf");

plotdf([y,x-x^3-a*y],[x,-5,5],[y,-5,5],[sliders,"a=-10:10"]);

\(\mathbf{\underline{\mbox{When }\gamma=0}}\)

\(\mathbf{\underline{\mbox{When }\gamma=2}}\)

\(\mathbf{\underline{\mbox{When }\gamma=-2}}\)

I have the phase portraits too but I don't know how to find the attractor basin still.



[Dustinsfl]

Change the ODE to a system of ODEs, we have
\begin{alignat}{3}
x_1' & = & x_2\\
x_2' & = & x_1 - x_1^3 + \gamma x_2
\end{alignat}
When $\gamma = 1$, how do I find the attraction basin?

Typo $-\gamma x_2$.



[Sudharaka]

Typo $-\gamma x_2$.

Note that I have corrected that in post #3.

I have the phase portraits too but I don't know how to find the attractor basin still.

Here is a figure that roughly depicts the attraction basins for the fixed points, \((1,0)\) and \((-1,0)\). The green region is the attractor basin of \((-1,0)\) and the red region is the attractor basin of \((1,0)\).



[Dustinsfl]

How do you find the attractor basin?



[Sudharaka]

How do you find the attractor basin?

I am not sure whether I understand your question here. The basins of attraction for \(\gamma=1\) are depicted in the figure in post #6.
