Even Engineers Doodle -- on the ICs they design

  • Thread starter Thread starter Tom.G
  • Start date Start date
  • Tags Tags
    Ic Microscope
Click For Summary
Engineers often leave small doodles or symbols on the surfaces of integrated circuits (ICs), which can be discovered when the chips are decapped for analysis. These hidden designs sometimes include team member names or logos, adding a personal touch to the technology. The practice of searching for these doodles has sparked renewed interest among engineers in examining older chips. This playful aspect of engineering highlights the creativity involved in chip design, even at a microscopic level. Such discoveries serve as a reminder of the human element behind technological advancements.
Engineering news on Phys.org
Yeah, whenever we used to de-cap another manufacturer's IC to figure out what went wrong, we would always look around the IC surface to see if they'd left any logos or similar. Every once in a while you might find the project team member names or some interesting symbol... :smile:

  • Like
Likes davenn and sophiecentaur
If you ever see similar doodles inside some random prototype ASIC, you now know where they came from.


Last edited:
  • Like
Likes Delta Prime, sophiecentaur and berkeman
Ok, that’s pretty cool. Kudos to the people behind them.

  • Like
Likes sophiecentaur
berkeman said:
Yeah, whenever we used to de-cap another manufacturer's IC to figure out what went wrong, we would always look around the IC surface to see if they'd left any logos or similar. Every once in a while you might find the project team member names or some interesting symbol... :smile:

for sure
gosh, it's been years since i last did that
i have been reinspired tp decap a few more chips :smile::smile:

Hello! I want to generate an RF magnetic field at variable frequencies (from 1 to 20 MHz) using this amplifier: https://www.minicircuits.com/WebStore/dashboard.html?model=LZY-22%2B, by passing current through a loop of current (assume the inductive resistance is negligible). How should I proceed in practice? Can i directly connect the loop to the RF amplifier? Should I add a 50 Ohm in series? Thank you!
