Power Hydraulics: Calculate Cylinder Diameter

  • Context: Undergrad
  • Thread starter Thread starter george88b
  • Start date Start date
  • Tags Tags
    Hydraulics Power
Click For Summary
SUMMARY

The discussion focuses on calculating the cylinder diameter in a hydraulic circuit with a pressure of 72 bar and a rod diameter of 15 mm. The retract speed of the cylinder is stated to be four times faster than the extend speed. To find the outer cylinder diameter, participants suggest using the area of circles, where the area of the outer circle is four times greater than the area of the inner circle. The pressure is deemed irrelevant for this calculation.

PREREQUISITES
  • Understanding of hydraulic systems and principles
  • Knowledge of geometric calculations involving circles
  • Familiarity with flow rate equations, specifically Q=V x A
  • Basic understanding of pressure in hydraulic circuits
NEXT STEPS
  • Research geometric properties of circles to understand area calculations
  • Learn about hydraulic flow rates and their implications in system design
  • Study the relationship between speed and area in hydraulic cylinders
  • Explore advanced hydraulic circuit design principles for efficiency
USEFUL FOR

Hydraulic engineers, mechanical engineers, and students studying fluid mechanics who are involved in designing or analyzing hydraulic systems.

george88b
Messages
8
Reaction score
0
hello..i m phasing a problem..i have an hydraulic circuit with pressure 72 bar and i want to find the cylinder diameter. I have that rod diameter is 15 mm and the speed of the cylinder is 4 times higher than the rod..please help me because i seraching days for this solution which i m sure that is very easy but i can't find nothing.. I think that the informations i have are not enough! thnx..

Physics news on Phys.org
If you're saying retract speed is 4X faster than extend speed...

Draw a circle inside of another circle. You are looking for the area of the outer circle. from that you can calculate the diameter and have your answer.

The area of the inner circle is known (15mm dia).

The area of the outer circle is 4x greater than the (area of the outer circle minus the area of inner circle).

Pressure is irrelevant. Is there enough information?

Evil Bunny said:
If you're saying retract speed is 4X faster than extend speed...

Draw a circle inside of another circle. You are looking for the area of the outer circle. from that you can calculate the diameter and have your answer.

The area of the inner circle is known (15mm dia).

The area of the outer circle is 4x greater than the (area of the outer circle minus the area of inner circle).

Pressure is irrelevant. Is there enough information?

i know that Q=V x A..SO--> 4V x A=V x (A-a) and then i can find A..Is that right?
