AC Current versus AC Voltage on the Neutral Wire of AC Mains

In summary: Can you explain the voltage drop across a neutral wire in terms of the equations?Problem Statement: AC CurrentRelevant Equations: -Sir how can one explain with the help of an analogy to a grade 10th student the reason behind not getting a shock on touching the neutral wire of the household AC circuit, even though the current flows alternately through live as well as neutral wires.A neutral wire has a drop in voltage of around 5 volts when it is connected to the live and neutral wires in a household circuit.
  • #1
Sarrah
13
1
Homework Statement
AC Current
Relevant Equations
-
Sir how can one explain with the help of an analogy to a grade 10th student the reason behind not getting a shock on touching the neutral wire of the household AC circuit, even though the current flows alternately through live as well as neutral wires.

Physics news on Phys.org
  • #2
Sarrah said:
Problem Statement: AC Current
Relevant Equations: -

Sir how can one explain with the help of an analogy to a grade 10th student the reason behind not getting a shock on touching the neutral wire of the household AC circuit, even though the current flows alternately through live as well as neutral wires.
I am not familiar with the home AC Mains electrical codes in your country. In the US, Neutral and Earth Ground are connected by Code at the home distribution panel, so there is very little voltage developed between Neutral and Earth Ground within a home. (Safety Note -- that assumes that the home has been wired to Code, and there are no faults in the system -- it is always a bad idea to use a human as a "shock/fault detector"; I hope you realize that.)

Can you post the relevant Code regulations for the country where you are teaching these students please? In the US, the Code requirements are published in the NEC.

243458

Last edited:
  • #3
And to add a very important safety note, when you say "touch" and "shock", you need to also mention what else the test dummy (literally) is touching. A bird on a high voltage wire will not feel a shock, because it is just sitting on one wire, with no other voltage references. A (stupid) person touching only a Hot or Neutral wire alone and nothing else will likewise not feel a shock.

But a person touching a Neutral wire and a Hot wire is risking their life, due to the large shock that they will experience. I once had a very discouraging discussion with a very experienced carpenter who tried to convince me that a GFCI would protect you if you grabbed Hot and Neutral in your two hands. I tried my best to explain to him how GFCIs only protect against faults from Hot to Ground, but he was having none of that. Hopefully you are smarter than that.

  • Like
Likes lomidrevo
  • #4
In normal situation, current flows through the neutral wire only when the loop is closed, i.e. when electrical appliance is connected (to hot wire also). In any case, touching the wires is strongly not recommend!

  • Like
Likes berkeman
  • #5
berkeman said:
I am not familiar with the home AC Mains electrical codes in your country. In the US, Neutral and Earth Ground are connected by Code at the home distribution panel, so there is very little voltage developed between Neutral and Earth Ground within a home. (Safety Note -- that assumes that the home has been wired to Code, and there are no faults in the system -- it is always a bad idea to use a human as a "shock/fault detector"; I hope you realize that.)

Can you post the relevant Code regulations for the country where you are teaching these students please? In the US, the Code requirements are published in the NEC.

View attachment 243458
Please explain as per your country's norms.

  • #6
Sarrah said:
Problem Statement: AC Current
Relevant Equations: -

Sir how can one explain with the help of an analogy to a grade 10th student the reason behind not getting a shock on touching the neutral wire of the household AC circuit, even though the current flows alternately through live as well as neutral wires.
The principle is that neutral stays at roughly Earth voltage while the line(s) vary relative to that.
As has been noted, this means that the neutral is in fact earthed at intervals in the distribution. Correspondingly, the power station is earthed on one side. Only the lines run on wires to the grid.
If there is a high current, I, on the circuit at the house then the voltage on the neutral can deviate from Earth by IR where R is the resistance of the neutral wire from where it is earthed to where you are touching the neutral. There is always the risk of a short, leading to a very high current and perhaps a dangerous voltage on the neutral. (And by resistance here I should include capacitative/inductive loads.)


Related to AC Current versus AC Voltage on the Neutral Wire of AC Mains

1. What is the difference between AC current and AC voltage on the neutral wire of AC mains?

AC current is the flow of electric charge in a circuit, while AC voltage is the potential difference or electrical pressure that drives the current. In AC mains, the neutral wire carries the return current back to the source, while the hot wire carries the alternating current. Therefore, the neutral wire has a voltage close to 0, while the hot wire has a higher voltage.

2. Why is AC current and voltage important to understand in AC mains?

Understanding AC current and voltage is important because they are the fundamental components of an AC circuit. They determine the power, efficiency, and safety of electrical systems. In AC mains, the proper balance of current and voltage is crucial for the safe and efficient operation of appliances and devices.

3. Can AC current flow without AC voltage on the neutral wire of AC mains?

No, AC current cannot flow without AC voltage on the neutral wire of AC mains. In order for current to flow, there must be a potential difference or voltage present to drive it. In an AC circuit, the voltage on the hot wire creates an alternating current that flows through the circuit and returns through the neutral wire.

4. What are the potential dangers of high AC current or voltage on the neutral wire of AC mains?

High AC current on the neutral wire can cause overloading and overheating of the wire, which can lead to fires. High AC voltage on the neutral wire can also be dangerous as it can cause electric shocks or damage to appliances and devices. It is important to ensure that the current and voltage on the neutral wire are within safe limits to prevent these hazards.

5. How can one measure AC current and voltage on the neutral wire of AC mains?

AC current can be measured using a clamp meter, which measures the magnetic field around the wire and calculates the current. AC voltage can be measured using a voltmeter, which measures the potential difference between two points in the circuit. Both of these tools are essential for monitoring and troubleshooting electrical systems in AC mains.
