First zvs driver+induction coil/heater HOT

  • Thread starter Thread starter 4TheResistance
  • Start date Start date
  • Tags Tags
    Hot
Click For Summary
SUMMARY

The forum discussion centers on the challenges faced while building a ZVS (Zero Voltage Switching) driver with an induction coil. The user is utilizing two IRFP250N MOSFETs powered by a 12V 4A battery charger and a microwave capacitor rated at 0.80μF and 2100V AC. Despite modifications, including switching to three 1μF 250V capacitors in series, the MOSFETs continue to overheat, reaching temperatures of 130°F. The user seeks solutions to prevent MOSFET overheating while achieving effective heating with the induction coil.

PREREQUISITES
  • Understanding of ZVS driver circuits
  • Familiarity with MOSFET specifications and thermal management
  • Knowledge of capacitor ratings and configurations
  • Basic principles of induction heating
NEXT STEPS
  • Research MOSFET thermal management techniques
  • Learn about ZVS driver circuit optimization
  • Investigate alternative capacitor configurations for improved performance
  • Explore the use of heatsinks and thermal grease for MOSFET cooling
USEFUL FOR

This discussion is beneficial for hobbyists and engineers working on induction heating projects, particularly those interested in ZVS driver circuits and thermal management of MOSFETs.

4TheResistance
Messages
3
Reaction score
0
I am making my first zvs driver and when I got it "finished" all it did was get my inductor and mosfets hot, the screwdriver I had in the heater did nothing. I killed the power before any damage was done, I hope. My mosfets are 2 IRFP250n's and I am powering it with a 12V 4A battery charger. My capacitor is from a microwave, 0.80μf and 2100V AC, is this too big?

I am new to most of this so just assume I know nothing. I won't be offended.
I am open to all suggestions and will put a few pics up tomorrow.






Last edited:
Engineering news on Phys.org
I just changed the inductor to 4 0f these in parallel.

http://www.ebay.com/itm/120998332098?ssPageName=STRK:MEWNX:IT&_trksid=p3984.m1439.l2649

Still doesn't work. the mosfets climb to 130F very fast but my screw stays cool.

Ok my caps came in the mail today so I switched the monster cap for 3- 1μf 250v in series. My inductors are no longer getting hot but the caps get a "little warm" and the mosfets still get HOT. I can tell its working now though, got a piece of a coat hanger up to 100F but the mosfets were way hotter so I killed the power.

Other than heatsinks(I'm waiting for my thermal grease) is there something I can change to keep the mosfets from burning up?
