Total Resistance: Calculate 8Ω Circuit, Don't Get It?

2 replies · 2K views · last reply
paulwct
Messages
1
Reaction score
0
If all the lightbulb in pic have resistance of 12 [tex]\Omega[/tex], What is the total circuit's total resistance? And the answer supposed to be 8 but I don't get it how it got 8?
Please let me know

Attachments
  • Circuit schematic of Figure E4.19 drawn sideways, showing three resistors in a rectangular loop with a branch between two nodes, labelled with the resistor symbols and the text Figure E4.19 printed above and below.
    9.3 KB · Views: 405
Your picture is practically illegible, but more importantly, you need to show your attempt to figure it out yourself. Preferably using the provided template.

The answer's absolutely correct.
show us what u have done and what answer you get!
