Help Design a Human-Powered Helicopter

[Phrak]

http://en.wikipedia.org/wiki/Momentum_theory"

http://en.wikipedia.org/wiki/Blade_element_theory"



[Phrak]

My hopes are dashed (see my post #43) by the following outlandish rule...

http://www.vtol.org/awards/hphregs.html#4 .

4.1.2 The machine shall be a rotary wing configuration capable of vertical takeoff and landing in still air, and at least one member of the crew shall be non-rotating.

Or...I will require a freshly made, newborn volunteer, as light in weight as possible, to function as the fifth crew member, suspended in a non rotating, centrally located bassinette.



[Phrak]

After more internet searching than I expected in order to circumvent infant labor laws, I discovered that the "world's smallest midget" is 28 inches tall. With some proportional comparison, this yields a nominal body weight of 18 pounds. Erroring on the conservative side, I expect to obtain the services of a 25 pound dwarf to provide the requisite fifth, non-rotating crew member.

After providing for a crash cage and mechanism to provide non-rotation of the central crew member plus the supporting cables, the central mass should weigh an effective 50 pounds. With four cables tensioned at 200 pounds apiece running to each Condor pilot's center of lift, the fifth pilot should be suspended at an altitude of 1/16th the flight radius below each Condor's lifting surface.

After some back of the envelope considerations, the flight radius of each Condor should be about 400 feet. This implied that the fifth pilot will be suspended 25 feet below the lifting blades.

To meet the requirement:

4.4.1 The flight requirements shall consist of hovering for one minute while maintaining flight within a 10-meter square. During this time the lowest part of the machine shall exceed momentarily 3 meters above the ground.

the blades will be required to obtain 35 feet of altitude + 3 feet of suspended fifth pilot = 38 feet. This is within some small ground effect for each Condor (wingspan of 100 ft.).

The overall diameter of the Helicopter will be about 900 ft.



[Phrak]

Will each Condor provide the centrifugal force necessary to tension the cables to the 5th crew member?

Each Condor will obtain about 25 feet per second, based upon the information from Wikipedia.

Using

v^2 = ar

were v =25 feet per second
and r = 400 feet

The centripital acceleration of each Condor will be 1.6 foot pounds per sec². The mass of each Condor will be about 32 Kg plus pilot (wikipedia reference, again).

After some calculations, each Condor is capable of providing only 10 pounds of radial force to hold up the fifth crew member. This is unacceptable.

Ideas anyone?



[mheslep]

I'll absolutely dismiss it. The power that can be provided by a good cyclist is somewhere in the area of 300 W. Not only will you be hard pressed to find a very light person that can put out that kind of continuous power, ...

It's not very continuous, but olympic calibre athletes can do work at 600W for 6 minutes. Such an athlete might helo across a hefty lake then, never the channel.



[Cyrus]

It's not very continuous, but olympic calibre athletes can do work at 600W for 6 minutes. Such an athlete might helo across a hefty lake then, never the channel.

Damn, if they can do 600W for 6 mins that's extremely impressive.



[mheslep]

Damn, if they can do 600W for 6 mins that's extremely impressive.

To my mind, olympic rowers in these time frames (6 minutes), out perform any other athlete type.
The athletes are frequently tested on ergometers (flywheel machines). The world record a few years ago was http://en.wikipedia.org/wiki/List_of_world_records_in_rowing#Indoor_Records" of 590W, i.e. work done on the machine. Over 500M (1m 16s) these guys can exceed 1HP. I've tested at the 2k distance a hundred times in competition and came in, ehem, somewhat lower. The typical top 10 school college rower (male) will rate at about 430W.

BTW, the do-it-yourself helo would have to hold that record holder's 97kg, 2m to get that power:



[FredGarvin]

It's not very continuous, but olympic calibre athletes can do work at 600W for 6 minutes. Such an athlete might helo across a hefty lake then, never the channel.

Yeah. I wouldn't use that as a data point. Those are definitely outliers from the norm.



[mheslep]

Those are definitely outliers from the norm.

So is this idea of a human powered helo.



[Mech_Engineer]

The point is that a helicopter like is being proposed needs at least 1hp (745W) to fly (I'm still convinced it would be more, but flying within the ground effect does help). The problem is, every pound kills you, and "successful" designs like the Davinci III only had an available payload of 59kg (130lb) for the pilot. Even powerful professional athletes which are significatly heavier cannot sustain that kind of output for very long.



[Cyrus]

The point is that a helicopter like is being proposed needs at least 1hp (745W) to fly (I'm still convinced it would be more, but flying within the ground effect does help).

I just showed you a calculation concerning the power.

The problem is, every pound kills you, and "successful" designs like the Davinci III only had an available payload of 59kg (130lb) for the pilot. Even powerful professional athletes which are significatly heavier cannot sustain that kind of output for very long.

That's right exactly right, and the power goes with the weight^(3/2).



[Phrak]

Does anyone know how high Allen flew crossing the English channel?

My second question would be, what is ground effect as a function of wingspan?

Edit: I've been searching for Bryan Allen's estimated power output and weight while crossing the channel and haven't found them.



[FredGarvin]

Ground effect is essentially any height below one rotor diameter.

The aircraft was powered using pedals to drive a large two-bladed propeller. Piloted by amateur cyclist Bryan Allen, it completed the 35.8 km (22.2 mi) crossing in 2 hours and 49 minutes, achieving a top speed of 29 km/h (18 mph) and an average altitude of 1.5 metres (5 feet).

The empty mass of the structure was only 32 kg (71 lb), although the gross mass for the Channel flight was almost 100 kg (220 lb). To maintain the craft in the air it was designed with very long tapering wings (high aspect ratio), like those of a glider, allowing the flight to be undertaken with a minimum of power. In still air the required power was of the order of 0.4 horsepower (300 W), though even mild turbulence made this figure rise rapidly.



[Phrak]

That's nearly full ground effect. The root of the wing was maybe 10 feet and the tips another 10 feet or so. This compares to a span of 100 feet.

I would expect that ground effect is exponential decaying with height.

I think I should discover the difference in total ground effect to none. That is "What is the maximum percent gain in lift due to ground effect?"



[Phrak]

Didn't you like my last post Fred? This thread is about a contest with no practical application, isn't it?



[Phrak]

Fred, on a more serious note, the contents of prize state nothing limiting supporting equipment. Ground effect could be sustained throughout the required excursion to 10 feet by ducting the blades with a circular fence.

How are you at hovercraft ducted fans?



[Mech_Engineer]

Fred, on a more serious note, the contents of prize state nothing limiting supporting equipment. Ground effect could be sustained throughout the required excursion to 10 feet by ducting the blades with a circular fence.

How are you at hovercraft ducted fans?

You couldn't have a giant duct, because the rules state the lowest part of the "helicopter" has to attain the maximum height. The bottom portion of the "ducts" would therefore have to reach the height.

I doubt you could justify such a system weight-wise anyway.



[dr dodge]

"4.1.4 No devices for storing energy either for takeoff or for use in flight shall be permitted. Rotating aerodynamic components, such as rotor blades, used for lift and/or control are exempt from consideration as energy storing devices"

couldn't you use multiple staged rotors with a gearing so it took maybe an hour to get everything rotating in a "no lift mode" then after critical rotation is reached, pull on the stick to get the pitch needed. during "run up" with a rotor not fighting for lift, I would think rotational velocity could be brought up high enough that inertia would then help keep it rotating with less immediate power needed?

just a little sprinkle to add to the current brainstorm

dr



[Cyrus]

"4.1.4 No devices for storing energy either for takeoff or for use in flight shall be permitted. Rotating aerodynamic components, such as rotor blades, used for lift and/or control are exempt from consideration as energy storing devices"

couldn't you use multiple staged rotors with a gearing so it took maybe an hour to get everything rotating in a "no lift mode" then after critical rotation is reached, pull on the stick to get the pitch needed. during "run up" with a rotor not fighting for lift, I would think rotational velocity could be brought up high enough that inertia would then help keep it rotating with less immediate power needed?

just a little sprinkle to add to the current brainstorm

dr

Why on Earth would you do such a thing? Think of it this way, what do you think will happen to the stresses at the hub when you suddenly dump the collective? The change in AoA will give a large impulsive pitching moment - bye bye blades.



[Phrak]

You couldn't have a giant duct, because the rules state the lowest part of the "helicopter" has to attain the maximum height. The bottom portion of the "ducts" would therefore have to reach the height.

I doubt you could justify such a system weight-wise anyway.

The fence or duct is attached to the ground, not the helicopter.



[Cyrus]

The fence or duct is attached to the ground, not the helicopter.

This is outside the spirit of the rules, and would not be allowed, for obvious reasons.



[FredGarvin]

Didn't you like my last post Fred? This thread is about a contest with no practical application, isn't it?

I can't really comment on it basically because I'm not sure where you are going with it. The reason ground effect exists is because of the blockage of reingested vortices at the rotor tips. It's either blocking that reingestion or it's not. I doubt there is any exponential decay of ground effect, or however you want to put it.

[EDIT] OK. So I did some looking after writing that, and found some references that disprove what I wrote. Seddon shows a theoretical expression (making a few major assumptions) that seems to work well in most cases:

\left[\frac{T}{T_\inf}\right] = \frac{1}{1-\frac{R}{4Z}^2}

This is supported by Figure 7 from Knight and Hefner:

http://naca.central.cranfield.ac.uk/reports/1941/naca-tn-835.pdf

I also found this graphic which I am kicking myself because I have seen this before (a longggggg time ago)

So it's not exponential, but it does decrease with increasing Z/R ratio. I stand humbly corrected.



[Phrak]

This is outside the spirit of the rules, and would not be allowed, for obvious reasons.

So it's within the rules, but outside some unstated rules?

To continue with this unspirited concept, it occurs to me that it might be equally beneficial to have 'ceiling' effect to double things up. I'm not sure if this makes sense.

Edit: I've re-read the rules, and the spirit erules to eliminate hovercraft and other stuff outside the intended box). But to be fair, all these attempts would have exploited ground effect.



[Mech_Engineer]

But to be fair, all these attempts would have exploited ground effect.

The only way one of these things can get off the ground is to exploit the ground effect. Too much power will be required to fly outside the ground effect, that's why these things barely make it a foot or two off the ground with 100ft rotor diameters.



[Cyrus]

The only way one of these things can get off the ground is to exploit the ground effect. Too much power will be required to fly outside the ground effect, that's why these things barely make it a foot or two off the ground with 100ft rotor diameters.

Additionally, the DaVinci III (with 100ft rotors) did not hover for very long because of stability. So you cannot say it was due to power issues. The Yuri had to stop its flight because it ran out of space due to drift. Again, a stability issue, not power. So sweeping statements about the power being too high are not strictly valid.



[dr dodge]

"Why on Earth would you do such a thing? Think of it this way, what do you think will happen to the stresses at the hub when you suddenly dump the collective?"

the main reason is that the total accumulated work over time is "banked" in an hour or two of "run up" in order to have momentum help to keep the rotors going with the available power from the pilot. Isn't the changing angle of attack what causes a conventional "rotor'd craft" to fly? If so, why in this application it assembly would self destruct?

dr



[Mech_Engineer]

Additionally, the DaVinci III (with 100ft rotors) did not hover for very long because of stability. So you cannot say it was due to power issues. The Yuri had to stop its flight because it ran out of space due to drift. Again, a stability issue, not power. So sweeping statements about the power being too high are not strictly valid.

Stability or no, the guy is pedaling like a maniac and barely made it a foot off the ground. If power were not a major issue, the craft would have been able to take off and consistently gain altitude with time. Instead, it seems to be they lift off and stabilize in altitude at a very low height.



[Cyrus]

Stability or no, the guy is pedaling like a maniac and barely made it a foot off the ground. If power were not a major issue, the craft would have been able to take off and consistently gain altitude with time. Instead, it seems to be they lift off and stabilize in altitude at a very low height.

But they don't stabilize at a low height. The blades were so long that any small angular deflection results in a tip strike. My point is that they did not have the stability to try and get to any significant height.



[Cyrus]

the main reason is that the total accumulated work over time is "banked" in an hour or two of "run up" in order to have momentum help to keep the rotors going with the available power from the pilot.

This is fundamentally wrong if you look at the power output curve of a person and the power demands of the aircraft. You simply do not want to use such a method.

Isn't the changing angle of attack what causes a conventional "rotor'd craft" to fly? If so, why in this application it assembly would self destruct?

dr

My understanding of what you have described is to spin up the rotors for an hour (and waste the pilots energy for no reason with a bunch of gearing that adds unnecessary weight) and suddenly change the collective on the blades. You would have to change the AoA of the blades quickly, otherwise they will slow back down. So you now need a larger, heavier blade hub to absorb the large transient stresses. This is idea gets worse and worse any way you slice it.



[mheslep]

My understanding of what you have described is to spin up the rotors for an hour (and waste the pilots energy for no reason with a bunch of gearing that adds unnecessary weight) and suddenly change the collective on the blades. You would have to change the AoA of the blades quickly, otherwise they will slow back down. So you now need a larger, heavier blade hub to absorb the large transient stresses. This is idea gets worse and worse any way you slice it.

Not only that, but Dodge is essentially suggesting an energy storage scheme, in this case storing energy in the blades angular momentum, which is against the rules.



[russ_watters]

So it's within the rules, but outside some unstated rules?

Phrak, please drop this line of discussion, as it is distracting from the purpose of the thread. You're not the one who gets to interpret the rules of the contest, the people running it are. So it isn't useful to try an weasel around them for the purpose of discussing it in this forum, when it is obvious that such weaseling wouldn't fly with the organizers of the contest.



[russ_watters]

Not only that, but Dodge is essentially suggesting an energy storage scheme, in this case storing energy in the blades angular momentum, which is against the rules.

On that point, I'm not so sure the judges would agree. Yes, he's essentially saying to use the rotors as flywheels, but the judges may consider that acceptible. The rules certainly imply it where they give a specific exemption from that rule for rotors.



[Cyrus]

Not only that, but Dodge is essentially suggesting an energy storage scheme, in this case storing energy in the blades angular momentum, which is against the rules.

What he said is OK, it's not energy storage because the pilot put in his own energy to spin up the rotors and then went on with the flight. However, it's a useless endeavour.

What you could not do, is spin them up, and have someone else jump in and then take off. Or, store energy in a spring, and then come back an hour later and try to fly after you are refreshed, along with the help of the spring.



[mheslep]

What he said is OK, it's not energy storage because the pilot put in his own energy to spin up the rotors and then went on with the flight. However, it's a useless endeavour.

What you could not do, is spin them up, and have someone else jump in and then take off. Or, store energy in a spring, and then come back an hour later and try to fly after you are refreshed, along with the help of the spring.

You need not switch out the human. If they allow energy storage as long as it is 'the same continuous operator', then someone could leisurely store up 100 watt-hours in an hour of work/pedalling and then release it all via some mechanism (e.g. electric motor) at the rate of 6kw (8HP) for one minute of flight, collect $20k, thank you. But this is moot, storing energy is not the goal of this exercise.



[Phrak]

I can't really comment on it basically because I'm not sure where you are going with it. The reason ground effect exists is because of the blockage of reingested vortices at the rotor tips. It's either blocking that reingestion or it's not. I doubt there is any exponential decay of ground effect, or however you want to put it.

[EDIT] OK. So I did some looking after writing that, and found some references that disprove what I wrote. Seddon shows a theoretical expression (making a few major assumptions) that seems to work well in most cases:

\left[\frac{T}{T_\inf}\right] = \frac{1}{1-\frac{R}{4Z}^2}

This is supported by Figure 7 from Knight and Hefner:

http://naca.central.cranfield.ac.uk/reports/1941/naca-tn-835.pdf

I also found this graphic which I am kicking myself because I have seen this before (a longggggg time ago)

So it's not exponential, but it does decrease with increasing Z/R ratio. I stand humbly corrected.

Thanks Fred, that would help a great deal, but I'm afraid I can't figure out the variables.



[Phrak]

There is a good and obvious reason storing energy in the angular momentum of the rotors is not significantly useful. The energy storage increases as omega squared. The drag of the rotors also increases as omega squared and (delited) [directly proportional to the excess mass deleted, as this is in error, as pointed out by Cyrus]. The power required to keep the excess mass aloft is proportional to the excess mass. The best one can do is weight the ends of the rotors and hope you still have excess stored energy after 5 minutes to stay aloft.

Without doing any heavy mental lifting, this means that you have a short time to use the energy to give you the pop up to the 3 meter requirement You are then are required to keep the excess mass aloft in ground effect.



[Phrak]

Phrak, please drop this line of discussion, as it is distracting from the purpose of the thread. You're not the one who gets to interpret the rules of the contest, the people running it are. So it isn't useful to try an weasel around them for the purpose of discussing it in this forum, when it is obvious that such weaseling wouldn't fly with the organizers of the contest.

Didn't I already note that in a past thread?

I haven't come across a great deal of creative thinking on this thread. Two serious-money attempts at this have been made, without success, using fairly common approaches. Since then somewhat more rigid materials have become more commonly available. (How does the specific modulus of commercially fabricable carbon-carbon compare to aluminum or steel? The last two are equal.)

I offered a very feasible helicopter that no one seems to given noticed. Why is that? It’s difficult to expect much from one's fellow posters, without some prodding, after such a blank reception.

Do you have anything yourself?



[Cyrus]

Didn't I already note that in a past thread?

I haven't come across a great deal of creative thinking on this thread. Two serious-money attempts at this have been made, without success, using fairly common approaches. Since then somewhat more rigid materials have become more commonly available. (How does the specific modulus of commercially fabricable carbon-carbon compare to aluminum or steel? The last two are equal.)

You are under the false premise that they were not made of carbon fiber - they were.

I offered a very feasible helicopter that no one seems to given noticed. Why is that? It’s difficult to expect much from one's fellow posters, without some prodding, after such a blank reception.

Did you mean two hang gliders 900' apart?



[Cyrus]

The drag of the rotors also increases as omega squared and directly proportional to the excess mass.

Come again? Drag has nothing to do with mass.



[Phrak]

Come again? Drag has nothing to do with mass.

My mistake. Drag increases as omega squared, but not proportional to the mass.

What do you think of wing tips on the rotors? I didn't seen any on the attempted craft. Would they contribute to adverse to the individual rotors around their axiis? Or result in flutter?



[Cyrus]

My mistake. Drag increases as omega squared, but not proportional to the mass.

What do you think of wing tips on the rotors? I didn't seen any on the attempted craft. Would they contribute to adverse to the individual rotors around their axiis? Or result in flutter?

To be formally correct, it increases with the tangential velocity, (r*omega)^2. I thought about wingtips but there was a reason why they were not justified. I can't remember right now, but I'll look up why and post later. Aerodynamically, there is only so much you can do here. In my mind, the key to getting this to work is a very clever structural design that is extremely light weight while meeting the stress requirements. This is much easier said that done. Quad anything means huge weight penalties, but inherent stability. A tip driven rotor, or coaxial means *significant* weight savings, but an unstable monster. Pick your poison.



[Phrak]

To be formally correct, it increases with the tangential velocity, r*omega^2. I thought about wingtips but there was a reason why they were not justified. I can't remember right now, but I'll look up why and post later. Aerodynamically, there is only so much you can do here. In my mind, the key to getting this to work is a very clever structural design that is extremely light weight while meeting the stress requirements. This is much easier said that done. Quad anything means huge weight penalties, but inherent stability. A tip driven rotor, or coaxial means *significant* weight savings, but an unstable monster. Pick your poison.

I have concern over the upward bending of each rotor as a result of lift. This is forth order, isn't it? Do you number for this?



[Cyrus]

I have concern over the upward bending of each rotor as a result of lift. This is forth order, isn't it? Do you number for this?

It's called coning. All rotors, including regular helicopters, do this.



[Phrak]

Sorry to be criptic. All I know is that torsional rigidity of a tube is to the forth power of the radius.



[Phrak]

We've gotten out of sync. But now that I know you are talking about a hinged rotor rather than rigid, I think you will have too much coning, won't you? Is there a way to suppress it?



[Phrak]

You are under the false premise that they were not made of carbon fiber - they were.]

carbon-carbon



[Cyrus]

We've gotten out of sync. But now that I know you are talking about a hinged rotor rather than rigid, I think you will have too much coning, won't you? Is there a way to suppress it?

I didn't say anything specific to a hinged rotor. The rotor will cone no matter what the hub attachment. The only way to minimize this is to increase stiffness, which will inevitably come from a heavier blade - unless you can find a material that is stiff in the direction you need for the same weight (good luck).



[Phrak]

I didn't say anything specific to a hinged rotor. The rotor will cone no matter what the hub attachment. The only way to minimize this is to increase stiffness, which will inevitably come from a heavier blade - unless you can find a material that is stiff in the direction you need for the same weight (good luck).

Then we are talking about the same thing, where the limiting factor upon weight considerations in rididity over strength.

Materials to compare are carbon fiber/carbon from mesophase pitch that has higher Youngs modulus compared to carbon fiber derived from the more common polyacrylonitrile--popular for it's strength.

However the carbon fiber/carbon may be prohibitively expensive. It is carbon fiber composite that undergoes a second and sometimes third process of reheating then reintroduction of matrix material.



[dr dodge]

"4.1.4 No devices for storing energy either for takeoff or for use in flight shall be permitted. Rotating aerodynamic components, such as rotor blades, used for lift and/or control are exempt from consideration as energy storing devices"

its not against the rules
I can see how the added mass and complexity would start you down the road of diminishing returns
thanks for the explain

dr



[rplatter]

Interesting problem.

I would suggest starting with something that already exists, like a gyrocopter.
And yes, I know they require forward momentum to get moving, but they are light and run on low power.
If you could get the blade moving fast enough, you could achieve lift off.
Stability is another factor. Some Gyrocopters use gravity similar to the way a hanglider does. Shifting the weight of the pilot angles the collective.
Height would be controlled by speed of the blade.
Rotation becomes the difficult part here. Both of the blades and of the craft.
Possibly a counter rotating blade unit, or an angled fin projecting into the down draft.
attaching power to the blade unit becomes touchy if you are using a free hanging pilot compartment. maybe a belt mechanism or a universal joint. I would offset the drive shaft from the blade hub so you could use some type of gearing at that point and to minimize the difficulty of construction.

Another approach would be to use laminar air flow and instead of a bunch of blades just have a saucer.
If you spin a smooth plate it will force air out from the center. (Tesla turbine)
shape it in a dome shape and the air going out will be directed down also.
The dome/saucer will also provide structural support to the entire structure.
I would imagine that a fairly soft but strong material could be used, a large mylar sheet or something. With a belt around the outside edge to provice rigidity. Just stretch it tight and smooth.
You still have to deal with the craft rotation, but that may be simple.
